SKO concentrating tables are designed for the treatment and additional refinement of the gold-containing concentrate after the refinement units. They are used at the placer gold-concentrating sites (PGCS) and placer gold-concentrating units (PGCU). With the universal surface structure, the table can be used as a medium-fine and fine sand washing table or for laboratory purposes.
SKO-1 and SKO-2 concentrating tables are the models that are most popular among the customers of Gold Mine Technology. See their specifications below.
|
Specifications |
SKO-1 |
SKO-2 |
|
Deck area |
1 m2 |
2 m2 |
|
Stroke frequency |
300 min-1 |
300 min-1 |
|
Deck stroke length |
6-16 mm |
6-16 mm |
|
Capacity |
max 0.4 t/h |
max 1.2 t/h |
|
Power consumption |
1.5 kW |
2.2 kW |
|
Weight |
250 kg |
280 kg |
|
Dimensions (length, width, height) |
2059х733х924 mm |
2646х1050х982 mm |
|
Feed size |
0.01 - 2 mm |
0.1 - 3 mm |
|
Transverse deck tilt angle |
0-16° |
0-16° |
|
Longitudinal deck tilt angle |
0-6° |
0-6° |
SKO-1 concentrating table is produced for just seven days, SKO-2 concentrating table production takes up to 14 days. You can also purchase SKO-05 and PR-4 concentrating tables. Click on the link to see their main specifications.
Please call +7-923-333-10-48 or send your inquiry to goncharova.o@goldmine.gold more to get information about the availability of the concentrating tables in stock and to place an order.
