Description
It is specified for discharging of cobbed (up to 500 mm) bulk materials with the angle of natural slope not less than 44º, not susceptible for adhesion from bunkers and other accumulating reservoirs within the temperature range from -20 Cº to +5 Cº.
Specifications
| Tray width, mm | 1000±10 |
| Tray lenght, mm | 2700±10 |
| Oscillation amplitude of the tray, mm | 2,1-4,3 |
| Oscillation frequency of the box, s-1 | 12,2...16,5 |
| Vibration angle, grad. | 20 |
| Inclination angle of the bottom, grad. | 10 |
| Feeding lumps size, mm, not more | 500 |
| Outpoot, t/h | 50...500 |
| Drive engine power, kW | 11 |
|
Overall dimensions, mm lenght width height |
3180±50 1836±20 950±10 |
|
Frequency converter EI-7011-015H, 380B, 25A, N=11 кВт lenght width height weight |
228 300 215 6,6 |
| Weight of oscillation part of the feeder, kg | 1650 |
