Description
Heavy-duty throw screens are designed for dry screening of ferrous and non-ferrous metals ores and other bulk materials into two or three classes as per lump size.
Specifications
| Parameters | GIT-52MB |
|---|---|
| 1. Feeding fractions size, mm, not more than | 400 |
| 2. Capacity, t/h | 350-800 |
| 3. Screening surface type: | |
| Upper furnace grate with slot size, mm | 100 |
| Lower woven wire with cells sizes, mm | 20x20 |
| 4. Dimensions of the screening surface, mm | 1750 х 5000 |
| 5. Useful screening surface area of one deck, m2 | 8,8 |
| 6. Quantity of decks of screening surface, items | 2(1) |
| 7. Angle of slope of screening surface, degrees | 15 |
| 8. Vibrator power, kW | 22 |
| 9. Amplitude of screening surface fluctuations, mm, within | 6 - 9,6 |
| 10. Frequency of screening surface fluctuations, min.-1 (rpm) | 730 |
| 11. Overall dimensions of vibrating part of screen, mm, not more than | 5250x2190x1505 |
| 12. Weight, kg, without drive and cover | 7087 (4800 without screening surface) |
| 13. Weight with spare parts and accessories, kg | 7432 |
Heavy-duty throw screens are designed for dry screening of ferrous and non-ferrous metals ores and other bulk materials into two or three classes as per lump size.
